Surveying or land surveying is the technique, profession, and science of determining the terrestrial or three-dimensional position of points and the distances and angles between them. A land surveying professional is called a land surveyor. These points are usually on the surface of the Earth, and they are often used to establish land maps and boundaries for ownership, locations like building corners or the surface location of subsurface features, or other purposes required by government or civil law, such as property sales.

Surveyors work with elements of mathematics (geometry and trigonometry), physics, engineering and the law. They use equipment like total stations, robotic total stations, GPS receivers, prisms, 3D scanners, radios, handheld tablets, digital levels, and surveying software.

Surveying has been an element in the development of the human environment since the beginning of recorded history. The planning and execution of most forms of construction require it. It is also used in transport, communications, mapping, and the definition of legal boundaries for land ownership.

Equestria Daily: Build-A-Bear Survey Includes Friendship is Magic
www.equestriadaily.com



ACSM definitions

The American Congress on Surveying and Mapping (ACSM),defines surveying as the science and art of making all essential measurements to determine the relative position of points or physical and cultural details above, on, or beneath the surface of the Earth, and to depict them in a usable form, or to establish the position of points or details.

Also per ACSM, the type of surveying known as "land surveying" is the detailed study or inspection, as by gathering information through observations, measurements in the field, questionnaires, or research of legal instruments, and data analysis in the support of planning, designing, and establishing of property boundaries. It involves the re-establishment of cadastral surveys and land boundaries based on documents of record and historical evidence, as well as certifying surveys (as required by statute or local ordinance) of subdivision plats or maps, registered land surveys, judicial surveys, and space delineation. Land surveying can include associated services such as mapping and related data accumulation, construction layout surveys, precision measurements of length, angle, elevation, area, and volume, as well as horizontal and vertical control surveys, and the analysis and utilization of land survey data.

Build A Survey Video




History

Ancient surveying

Basic surveyance has occurred since humans built the first large structures. The prehistoric monument at Stonehenge (c. 2500 BC) was set out by prehistoric surveyors using peg and rope geometry.

In ancient Egypt, a rope stretcher would use simple geometry to re-establish boundaries after the annual floods of the Nile River. The almost perfect squareness and north-south orientation of the Great Pyramid of Giza, built c. 2700 BC, affirm the Egyptians' command of surveying. The Groma instrument originated in Mesopotamia (early 1st millennium BC).

The mathmetician Liu Hui described ways of measuring distant objects in his work Haidao suanjing or The Sea Island Mathematical Manual, published in 263 AD.

The Romans recognized land surveyors as a profession. They established the basic measurements under which the Roman Empire was divided, such as a tax register of conquered lands (300 AD). Roman surveyors were known as Gromatici.

In medieval Europe, beating the bounds maintained the boundaries of a village or parish. This was the practice of gathering a group of residents and walking around the parish or village to establish a communal memory of the boundaries. Young boys were included to ensure the memory lasted as long as possible.

In England, William the Conqueror commissioned the Domesday Book in 1086. It recorded the names of all the land owners, the area of land they owned, the quality of the land, and specific information of the area's content and inhabitants. It did not include maps showing exact locations.

Modern surveying

Abel Foullon described a plane table in 1551, but it is thought that the instrument was in use earlier as his description is of a developed instrument.

Gunter's chain was introduced in 1620 by English mathematician Edmund Gunter. It enabled plots of land to be accurately surveyed and plotted for legal and commercial purposes.

Leonard Digges described a Theodolite that measured horizontal angles in his book A geometric practice named Pantometria (1571). Joshua Habermel (de:Erasmus Habermehl) created a theodolite with a compass and tripod in 1576. Johnathon Sission was the first to incorporate a telescope on a theodolite in 1725.

In the 18th century, modern techniques and instruments for surveying began to be used. Jesse Ramsden introduced the first precision theodolite in 1787. It was an instrument for measuring angles in the horizontal and vertical planes. He created his great theodolite using an accurate dividing engine of his own design. Ramsden's theodolite represented a great step forward in the instrument's accuracy. William Gascoigne invented an instrument that used a telescope with an installed crosshair as a target device, in 1640. James Watt developed an optical meter for the measuring of distance in 1771; it measured the parallactic angle from which the distance to a point could be deduced.

Dutch mathematician Willebrord Snellius (a.k.a. Snell) introduced the modern systematic use of triangulation. In 1615 he surveyed the distance from Alkmaar to Bergen op Zoom, approximately 70 miles (110 kilometres). The survey was a chain of quadrangles containing 33 triangles in all. Snell showed how planar formulae could be corrected to allow for the curvature of the earth. He also showed how to resection, or calculate, the position of a point inside a triangle using the angles cast between the vertices at the unknown point. These could be measured more accurately than bearings of the vertices, which depended on a compass. His work established the idea of surveying a primary network of control points, and locating subsidiary points inside the primary network later. Between 1733 and 1740, Jacques Cassini and his son César undertook the first triangulation of France. They included a re-surveying of the meridian arc, leading to the publication in 1745 of the first map of France constructed on rigorous principles. By this time, triangulation methods were by then well established for local map-making,

It was only towards the end of the 18th century that detailed triangulation network surveys mapped whole countries. In 1784, a team from General William Roy's Ordnance Survey of Great Britain began the Principal Triangulation of Britain. The first Ramsden theodolite was built for this survey. The survey was finally completed in 1853. The Great Trigonometric Survey of India began in 1801. The Indian survey had an enormous scientific impact. It was responsible for one of the first accurate measurements of a section of an arc of longitude, and for measurements of the geodesic anomaly. It named and mapped Mount Everest and the other Himalayan peaks. Surveying became a professional occupation in high demand at the turn of the 19th century with the onset of the Industrial Revolution. The profession developed more accurate instruments to aid its work. Industrial infrastructure projects used surveyors to lay out canals, roads and rail,

In the US, the Land Ordinance of 1785 created the Public Land Survey System. It formed the basis for dividing the western territories into sections to allow the sale of land. The PLSS divided states into township grids which were further divided into sections and fractions of sections.

Napoleon Bonaparte founded continental Europe's first cadastre in 1808. This gathered data on the number of parcels of land, their value, land usage, and names. This system soon spread around Europe.

Robert Torrens introduced the Torrens system in South Australia in 1858. Torrens intended to simplify land transactions and provide reliable titles via a centralized register of land. The Torrens system was adopted in several other nations of the English-speaking world.

20th century

At the beginning of the century surveyors had improved the older chains and ropes, but still faced the problem of accurate measurement of long distances. Dr Trevor Lloyd Wadley developed the Tellurometer during the 1950s. It measures long distances using two microwave transmitter/receivers. During the late 1950s Geodimeter introduced electronic distance measurement (EDM) equipment. EDM units use a multi frequency phase shift of light waves to find a distance. These instruments saved the need for days or weeks of chain measurement by measuring between points kilometers apart in one go.

Advances in electronics allowed miniaturization of EDM. In the 1970s the first instruments combining angle and distance measurement appeared, becoming known as total stations. Manufacturers added more equipment by degrees, bringing improvements in accuracy and speed of measurement. Major advances include tilt compensators, data recorders, and on-board calculation programs.

The first Satellite positioning system was the US Navy TRANSIT system. The first successful launch took place in 1960. The system's main purpose was to provide position information to Polaris missile submarines. Surveyors found they could use field receivers to determine the location of a point. Sparse satellite cover and large equipment made observations laborious, and inaccurate. The main use was establishing benchmarks in remote locations.

The US Air force launched the first prototype satellites of the Global Positioning System (GPS) in 1978. GPS used a larger constellation of satellites and improved signal transmission to provide more accuracy. Early GPS observations required several hours of observations by a static receiver to reach survey accuracy requirements. Recent improvements to both satellites and receivers allow Real Time Kinematic (RTK) surveying. RTK surveys get high-accuracy measurements by using a fixed base station and a second roving antenna. The position of the roving antenna can be tracked.

21st century

The theodolite, total station, and RTK GPS survey remain the primary methods in use.

Remote sensing and satellite imagery continue to improve and become cheaper, allowing more commonplace use. Prominent new technologies include three-dimensional (3D) scanning and use of lidar for topographical surveys.

Build Mobile Surveys, Not Technical Survey Platforms | Mobile Response
mobileresponse.com


Surveying equipment

The main surveying instruments in use around the world are the theodolite and steel band, the total station, the level and rod and surveying GPS systems. Most instruments screw onto a tripod when in use. Tape measures are often used for measurement of smaller distances. 3D scanners and various forms of aerial imagery are also used.

The Theodolite is an instrument for the measurement of angles. It uses two separate circles, protractors or alidades to measure angles in the horizontal and the vertical plane. A telescope mounted on trunnions is aligned vertically with the target object. The whole upper section rotates for horizontal alignment. The vertical circle measures the angle that the telescope makes against the vertical, known as the vertical angle. The horizontal circle uses an upper and lower plate. When beginning the survey, the surveyor points the instrument in a known direction (bearing), and clamps the lower plate in place. The instrument can then rotate to measure the bearing to other objects. If no bearing is known or direct angle measurement is wanted, the instrument can be set to zero during the initial sight. It will then read the angle between the initial object, the theodolite itself, and the item that the telescope aligns with.

The Gyrotheodolite is a form of theodolite that uses a gyroscope to orient itself in the absence of reference marks. It is used in underground applications.

The total station is a development of the theodolite with an electronic distance measurement device (EDM). A total station can be used for leveling when set to the horizontal plane. Since their introduction, total stations have shifted from optical-mechanical to fully electronic devices.

Modern top-of-the-line total stations no longer need a reflector or prism to return the light pulses used for distance measurements. They are fully robotic, and can even e-mail point data to a remote computer and connect to satellite positioning systems, such as Global Positioning System. Real Time Kinematic GPS systems have increased the speed of surveying, but they are still only horizontally accurate to about 20 mm and vertically to 30-40 mm.

GPS surveying differs from other GPS users in the equipment and methods used. Static GPS uses two receivers placed in position for a considerable length of time. The long span of time lets the receiver compare measurements as the satellites orbit. The changes as the satellites orbit also provide the measurement network with well conditioned geometry. This produces an accurate baseline that can be over 20 km long. RTK surveying uses one static antenna and one roving antenna. The static antenna tracks changes in the satellite positions and atmospheric conditions. The surveyor uses the roving antenna to measure the points needed for the survey. The two antennas use a radio link that allows the static antenna to send corrections to the roving antenna. The roving antenna then applies those corrections to the GPS signals it is receiving to calculate its own position. RTK surveying covers smaller distances than static methods. This is because divergent conditions further away from the base reduce accuracy.

Surveying instruments have characteristics that make them suitable for certain uses. Theodolites and levels are often used by constructors rather than surveyors in first world countries. The constructor can perform simple survey tasks using a relatively cheap instrument. Total stations are workhorses for many professional surveyors because they are versatile and reliable in all conditions. The productivity improvements from a GPS on large scale surveys makes them popular for major infrastructure or data gathering projects. One-person robotic-guided total stations allow surveyors to measure without extra workers to aim the telescope or record data. A fast but expensive way to measure large areas is with a helicopter, using a GPS to record the location of the helicopter and a laser scanner to measure the ground. To increase precision, surveyors place beacons on the ground (about 20 km (12 mi) apart). This method reaches precisions between 5-40 cm (depending on flight height).

Surveyors use ancillary equipment such as: tripods and instrument stands; staves and beacons used for sighting purposes; PPE; vegetation clearing equipment; digging implements for finding survey markers buried over time; hammers for placements of markers in various surfaces and structures; and portable radios for communication over long lines of sight.

How to quickly build a Survey using SharePoint 2013 - SiteActions
www.siteactions.net


Surveying techniques

Surveyors determine the position of objects by measuring angles and distances. The factors that can affect the accuracy of their observations are also measured. They then use this data to create vectors, bearings, co-ordinates, elevations, areas, volumes, plans and maps. Measurements are often split into horizontal and vertical components to simplify calculation. GPS and astronomic measurements also need measurement of a time component.

Distance measurement

Before EDM devices, distances were measured using a variety of means. These included chains having links of a known length such as a Gunter's chain, or measuring tapes made of steel or invar. To measure horizontal distances, these chains or tapes were pulled taut to reduce sagging and slack. The distance had to be adjusted for heat expansion. Attempts to hold the measuring instrument level would also be made. When measuring up a slope, the surveyor might have to "break" (break chain) the measurement- use an increment less than the total length of the chain. Perambulators, or measuring wheels, were used to measure longer distances but not to a high level of accuracy. Tacheometry is the science of measuring distances by measuring the angle between two ends of an object with a known size. It was sometimes used before to the invention of EDM where rough ground made chain measurement impractical.

Angle measurement

Historically, horizontal angles were measured by using a compass to provide a magnetic bearing. The deflection from the bearing was recorded. Later, more precise scribed discs later improved better angular resolution. Mounting telescopes with reticles atop the disc allowed more precise sighting. (see theodolite). Levels and calibrated circles allowed measurement of vertical angles. verniers allowed measurement to a fraction of a degree, such as with a turn-of-the-century transit.

The Plane table provided a graphical method of recording and measuring angles, which reduced the amount of mathematics required.

By observing the bearing from every vertex in a figure, a surveyor can measure around the figure. The final observation will be between the two points first observed, except with a 180° difference. This is called a close. If the first and last bearings are different, this shows the error in the survey, called the angular misclose. The surveyor can use this information to prove that the work meets the expected standards.

Levelling

The simplest method for measuring height is with an altimeter using air pressure to find height. When more precise measurements are needed, means like precise levels (also known as differential leveling) are used. When precise leveling, a series of measurements between two points are taken using an instrument and a measuring rod. Differences in height between the measurements are added and subtracted in a series to get the net difference in elevation between the two endpoints. With the Global Positioning System (GPS), elevation can be measured with satellite receivers. Usually GPS is somewhat less accurate than traditional precise leveling, but may be similar over long distances.

When using an optical level, the endpoint may be out of the effective range of the instrument. There may be obstructions or large changes of elevation between the endpoints. In these situations, extra setups are needed. Turning is a term used when referring to moving the level to take an elevation shot from a different location. To "turn" the level, one must first take a reading and record the elevation of the point the rod is located on. While the rod is being kept in exactly the same location, the level is moved to a new location where the rod is still visible. A reading is taken from the new location of the level and the height difference is used to find the new elevation of the level gun. This is repeated until the series of measurements is completed. The level must be horizontal to get a valid measurement. Because of this, if the horizontal crosshair of the instrument is lower than the base of the rod, the surveyor will not be able to sight the rod and get a reading. The rod can usually be raised up to 25 feet high, allowing the level to be set much higher than the base of the rod.

Determining position

The primary way of determining one's position on the earth's surface when no known positions are nearby is by astronomic observations. Observations to the sun, moon and stars could all be made using navigational techniques. Once the instrument's position and bearing to a star is determined, the bearing can be transferred to a reference point on the earth. The point can then be used as a base for further observations. Survey-accurate astronomic positions were difficult to observe and calculate and so tended to be a base off which many other measurements were made. Since the advent of the GPS system, astronomic observations are rare as GPS allows adequate positions to be determined over most of the surface of the earth.

Reference networks

Few survey positions are derived from first principles. Instead, most surveys points are measured relative to previous measured points. This forms a reference or control network where each point can be used by a surveyor to determine their own position when beginning a new survey.

Survey points are usually marked on the earth's surface by objects ranging from small nails driven into the ground to large beacons that can be seen from long distances. The surveyors can set up their instruments on this position and measure to nearby objects. Sometimes a tall, distinctive feature such as a steeple or radio aerial has its position calculated as a reference point that angles can be measured against.

Triangulation is a method of horizontal location favoured in the days before EDM and GPS measurement. It can determine distances, elevations and directions between distant objects. Since the early days of surveying, this was the primary method of determining accurate positions of objects for topographic maps of large areas. A surveyor first needs to know the horizontal distance between two of the objects, known as the baseline. Then the heights, distances and angular position of other objects can be derived, as long as they are visible from one of the original objects. High-accuracy transits or theodolites were used, and angle measurements repeated for increased accuracy. See also Triangulation in three dimensions.

Offsetting is an alternate method of determining position of objects, and was often used to measure imprecise features such as riverbanks. The surveyor would mark and measure two known positions on the ground roughly parallel to the feature, and mark out a baseline between them. At regular intervals, a distance was measured at right angles from the first line to the feature. The measurements could then be plotted on a plan or map, and the points at the ends of the offset lines could be joined to show the feature.

Traversing is a common method of surveying smaller areas. The surveyor starts from an old reference mark or known position and places a network of reference marks covering the survey area. They then measure bearings and distances between the reference marks, and to the target features. Most traverses form a loop pattern or link between two prior reference marks to allow the surveyor to check their measurements are correct.

Datum and coordinate systems

Many surveys do not calculate positions on the surface of the earth, but instead measure the relative positions of objects. However, often the surveyed items need to be compared to outside data, such as boundary lines or previous surveys objects. The oldest way of describing a position is via latitude and longitude, and often a height above sea level. As the surveying profession grew it created Cartesian coordinate systems to simplify the mathematics for surveys over small parts of the earth. The simplest coordinate systems assume that the earth is flat and measure from an arbitrary point, known as a 'datum' (singular form of data). The coordinate system allows easy calculation of the distances and direction between objects over small areas. Large areas distort due to the earth's curvature. North is often defined as true north at the datum.

For larger regions, it is necessary to model the shape of the earth using an ellipsoid or a geoid. Many countries have created coordinate-grids customized to lessen error in their area of the earth.

Errors and accuracy

A basic tenet of surveying is that no measurement is perfect, and that there will always be a small amount of error. There are three classes of survey errors:

  • Gross errors or blunders: Errors made by the surveyor during the survey. Upsetting the instrument, misaiming a target, or writing down a wrong measurement are all gross errors. A large gross error may reduce the accuracy to an unacceptable level. Therefore, surveyors use redundant measurements and independent checks to detect these errors early in the survey.
  • Systematic: Errors that follow a consistent pattern. Examples include effects of temperature on a chain or EDM measurement, or a poorly adjusted spirit-level causing a tilted instrument or target pole. Systematic errors that have known effects can be compensated or corrected.
  • Random: Random errors are small unavoidable fluctuations. They are caused by imperfections in measuring equipment, eyesight, and conditions. They can be minimized by redundancy of measurement and avoiding unstable conditions. Random errors tend to cancel each other out, but checks must be made to ensure they are not propagating from one measurement to the next.

Surveyors avoid these errors by regular checks on their equipment, using consistent methods, and by good design of their reference network. Redundancy of measurements allows the use of averaging and allows outlier measurements to be discarded. Independent checks like measuring a point from two or more locations or using two different methods are used. Errors can be detected by comparing the results of the two measurements.

Once the surveyor has calculated the level of the errors in his work, it is adjusted. This is the process of distributing the error between all measurements. Each observation is weighted according to how much of the total error it is likely to have caused and part of that error is allocated to it in a proportional way. The most common methods of adjustment are the Bowditch method, also known as the compass rule, and the Principle of least squares method.

The Surveyor must be able to distinguish between accuracy and precision. In the United States, surveyors and civil engineers use units of feet wherein a survey foot breaks down into 10ths and 100ths. Many deed descriptions containing distances are often expressed using these units (125.25 ft). On the subject of accuracy, surveyors are often held to a standard of one one-hundredth of a foot; about 1/8 inch. Calculation and mapping tolerances are much smaller wherein achieving near-perfect closures are desired. Though tolerances will vary from project to project, in the field and day to day usage beyond a 100th of a foot is often impractical.

How to Distribute Surveys | Distribute Survey
www.qualtrics.com


Types of surveys

Local professional organisation or regulatory bodies classify specializations of surveying in different ways. Broad groups are:

  • As-built survey: a survey that documents the location of recently constructed elements of a construction project. Asbuilt surveys are done for record, completion evaluation and payment purposes. An as-built survey is also known as a 'works as executed survey'. As built surveys are often presented in red or redline and laid over existing plans for comparison with design information.
  • Cadastral or boundary surveying: a survey that establishes or re-establishes boundaries of a parcel using a legal description. It involves the setting or restoration of monuments or markers at the corners or along the lines of the parcel. These take the form of iron rods, pipes, or concrete monuments in the ground, or nails set in concrete or asphalt. The ALTA/ACSM Land Title Survey is a standard proposed by the American Land Title Association and the American Congress on Surveying and Mapping. It incorporates elements of the boundary survey, mortgage survey, and topographic survey.
  • Control surveying: Control surveys establish reference points to use as starting positions for future surveys. Most other forms of surveying will contain elements of control surveying.
  • Construction surveying
  • Deformation survey: a survey to determine if a structure or object is changing shape or moving. First the positions of points on an object are found. A period of time is allowed to pass and the positions are then re-measured and calculated. Then a comparison between the two sets of positions is made.
  • Dimensional control survey: This is a type of survey conducted in or on an non-level surface. Common in the oil and gas industry to replace old or damaged pipes on a like-for-like basis. The advantage of dimensional control survey is that the instrument used to conduct the survey does not need to be level. This is useful in the off-shore industry, as not all platforms are fixed and are thus subject to movement.
  • Engineering surveying: topographic, layout, and as-built surveys associated with engineering design. They often need geodetic computations beyond normal civil engineering practice.
  • Foundation survey: a survey done to collect the positional data on a foundation that has been poured and is cured. This is done to ensure that the foundation was constructed in the location, and at the elevation, authorized in the plot plan, site plan, or subdivision plan.
  • Hydrographic survey: a survey conducted with the purpose of mapping the shoreline and bed of a body of water. Used for navigation, engineering, or resource management purposes.
  • Leveling: either finds the elevation of a given point or establish a point at a given elevation.
  • LOMA survey: Survey to change base flood line, removing property from a SFHA special flood hazard area.
  • Measured survey : a building survey to produce plans of the building. such a survey may be conducted before renovation works, for commercial purpose, or at end of the construction process.
  • Mining surveying: Mining surveying includes directing the digging of mine shafts and galleries and the calculation of volume of rock. It uses specialised techniques due to the restraints to survey geometry such as vertical shafts and narrow passages.
  • Mortgage survey: A mortgage survey or physical survey is a simple survey that delineates land boundaries and building locations. It checks for encroachment, building setback restrictions and shows nearby flood zones. In many places a mortgage survey is a precondition for a mortgage loan.
  • Photographic control survey: A survey that creates reference marks visible from the air to allow aerial photographs to be rectified.
  • Stakeout, Layout or Setout: an element of many other surveys where the calculated or proposed position of an object is marked on the ground. This can be temporary or permanent. This is an important component of engineering and cadastral surveying.
  • Structural survey: a detailed inspection to report upon the physical condition and structural stability of a building or structure. It highlights any work needed to maintain it in good repair.
  • Subdivision: A boundary survey that splits a property into two or more smaller properties.
  • Topographic survey: a survey that measures the elevation of points on a particular piece of land, and presents them as contour lines on a plot.
kb.uwp.edu


The surveying profession

The basic principles of surveying have changed little over the ages, but the tools used by surveyors have evolved. Engineering, especially civil engineering, often needs surveyors.

Surveyors help determine the placement of roads, railways, reservoirs, dams, pipelines, retaining walls, bridges, and buildings. They establish the boundaries of legal descriptions and political divisions. They also provide advice and data for geographical information systems (GIS) that record land features and boundaries.

Surveyors must have a thorough knowledge of algebra, basic calculus, geometry, and trigonometry. They must also know the laws that deal with surveys, real property, and contracts.

Most jurisdictions recognize three different levels of qualification:

Survey assistants or chainmen are usually unskilled workers who help the surveyor. They place target reflectors, find old reference marks, and mark points on the ground. The term 'chainman' derives from past use of measuring chains. An assistant would move the far end of the chain under the surveyor's direction.

Survey technicians often operate survey instruments, run surveys in the field, do survey calculations, or draft plans. A technician usually has no legal authority and cannot certify his work. Not all technicians are qualified, but qualifications at the certificate or diploma level are available.

Licensed, registered, or chartered surveyors usually hold a degree or higher qualification. They are often required to pass further exams to join a professional association or to gain certifying status. Surveyors are responsible for planning and management of surveys. They have to ensure that their surveys, or surveys performed under their supervision, meet the legal standards. Many principals of surveying firms hold this status.

Informal surveying

Not all surveys are carried out by professional surveyors. Depending on the jurisdiction and circumstances, the builders of a structure may set it out themselves. Surveyors often set out the most significant corners of a building. The builders then lay out the rest of the building themselves simple survey techniques.

Licensing

Licensing requirements vary with jurisdiction, and are commonly consistent within national borders.

United States

Most of the US recognizes surveying as a distinct profession apart from engineering.

Licensing requirements vary by state, but they have components of education, experience, and examinations. Most states insist upon the basic qualification of a degree in surveying, plus experience and examination requirements. In the past, candidates completed an apprenticeship before taking a series of examinations to gain licensure.

The licensing process follows two phases. Upon graduation, the candidate may take the Fundamentals of Surveying (FS) exam. If they pass and meet the other requirements they become a surveying intern (SI). Upon certification as an SI, the candidate then needs to gain on-the-job experience to become eligible for the second phase. In most states, this is the Principles and Practice of Land Surveying (PS) exam and a state-specific examination. SIs were formerly called surveyors in training (SIT).

Licensed surveyors usually denote themselves with post nominals. The letters PLS (professional land surveyor), PS (professional surveyor), LS (land surveyor), RLS (registered land surveyor), RPLS (Registered Professional Land Surveyor), or PSM(professional surveyor and mapper) follow their names, depending upon their jurisdiction of registration.

Canada

In Canada, land surveyors register to work in their respective province. The designation for a land surveyor breaks down by province. It follows the rule whereby the first letter indicates the province, followed by L.S. There is also a designation C.L.S. or Canada lands surveyor. They have the authority to work on Canada lands, which include Indian Reserves, National Parks, the three territories, and offshore lands.

Commonwealth

Many Commonwealth countries use the term Chartered Land Surveyor for someone holding a professional license.

Legal aspects

A licensed land surveyor is generally required to sign and seal all plans. The state dictates the format, showing their name and registration number.

In many jurisdictions, surveyors must mark their registration number on survey monuments when setting boundary corners. Monuments take the form of capped iron rods, concrete monuments, or nails with washers.

Surveying institutions

Most countries' governments regulate at least some forms of surveying. Their survey agencies establish regulations and standards. Standards control accuracy, surveying credentials, monumentation of boundaries and maintenance of geodetic networks. Many nations devolve this authority to regional entities or states/provinces. Cadastral surveys tend to be the most regulated because of the permanence of the work. Lot boundaries established by cadastral surveys may stand for hundreds of years without modification.

Most jurisdictions also have a form of professional institution representing local surveyors. These institutes often endorse or license potential surveyors, as well as set and enforce ethical standards. The largest institution is the International Federation of Surveyors (Abbreviated FIG, for French: Fédération Internationale des Géomètres). They represent the survey industry worldwide.

Building surveying

Most English-speaking countries consider building surveying a distinct profession. They have their own professional associations and licencing requirements. Building surveyors focus on investigating the condition of buildings as well as legal compliance work.

Cadastral surveying

One of the primary roles of the land surveyor is to determine the boundary of real property on the ground. The surveyor must determine where the adjoining landowners wish to put the boundary. The boundary is established in legal documents and plans prepared by attorneys, engineers, and land surveyors. The surveyor then puts monuments on the corners of the new boundary. They might also find or resurvey the corners of the property monumented by prior surveys.

Cadastral land surveyors are licensed by governments. The cadastral survey branch of the Bureau of Land Management (BLM) conducts most cadastral surveys in the United States. They consult with Forest Service, National Park Service, Army Corps of Engineers, Bureau of Indian Affairs, Fish and Wildlife Service, Bureau of Reclamation, and others. The BLM used to be known as the General Land Office (GLO).

In states organized per the Public Land Survey System (PLSS), surveyors must carry out BLM cadastral surveys under that system.

Cadastral surveyors often have to work around changes to the earth that obliterate or damage boundary monuments. When this happens, they must consider evidence that is not recorded on the title deed. This is known as extrinsic evidence.
